Hytube Titan TUBE CUTTER 6000W 20" Dia 4 Chuck Fiber Laser Pipe Cutting Machine

Hytube Titan TUBE CUTTER 6000W 20" Dia 4 Chuck Fiber Laser Pipe Cutting Machine

$580,000 (USD)

orCall 804.598.1780

Specifications

ManufacturerBescutter
ConditionNew
Tube range (length)40' (12000 mm)
Tube diameterUp to 20" cross diagonal
X-axis29.5' (9000 mm)
Y-axis8.86" (225 mm)
Un-loading tube length0- 236" (0-6000mm)
Cnc systemFSCUT5000
X, y-axis positioning accuracy±0.05 mm/1000 mm
X, y-axis re-positioning accuracy±0.03 mm
A, b-axis positioning accuracy±30"
A, b-axis re-positioning accuracy±10"
X, y-axis max positioning speed100 m/min
Max positioning speed60 rpm
Laser resonatorHans Photonics 6KW
Optional laser wattage3 KW/ 4 KW/ 6 KW
Laser headRayTools
Machine weight40,000 lbs
Dimensions (l x w x h)984"x 169" x 110" (25000 x 4300 x 2800 mm) auto-loading not included
