TUBE Ninja 4 In and Smaller | Fiber Laser Tube Cutting Machine With Automation
TUBE Ninja 4 In and Smaller | Fiber Laser Tube Cutting Machine With Automation
$75,000 (USD)
or
Call 804.598.1780
Specifications
| Manufacturer | Bescutter |
| Condition | New |
| Laser power | BC Power 1500W /2000W |
| Laser wavelength | 1070nm |
| Complete consumption | 19KW |
| Xyz axis position accuracy | ≤±0.05mm |
| Xyz axis repeat position accuracy | ≤±0.02mm |
| Min cutting kerf | 0.15mm |
| Acceleration | 1.8G |
| Max rpm | 160 |
| Machine weight | 2T |
| Machine size | 334" x 70" x 70" (8500 X 1800 X 1800 mm) |
| Power supply | AC 208/240 single phase 85A |
| Assistant air | Air Compressor / 0.8MPa |
| Water chiller | HANLI / HL 3000 Industrial Refrigerated Chiller |
